UV-1800SPC UV-V Spectrophotometer

This series of instruments easily simple photric analysis, quantitative analysis, dynamic analysis, spectral scanning, multiwavelength testing, DNA / protein analysis.

Instrumentation features:

1. The latest ARM system, built-in Chinese and English dual operating system, can be stored and transferred data through USB interface

2, powerful, the host can independently complete photometric measurement, quantitative measurement, spectral scanning, dynamics, DNA / protein testing, multi-wavelength testing and data printing and other functions.

3, the instrument uses 320 ` 240 dot array highlight 6 liquid crystal display, directly display the scanning map, the screen interface is simple, easy to use.

4, design a unique optical system, high performance 1200 bars / mm grating and imported receiver to ensure that the instrument has excellent performance indicators.

5, socket type atmosphere lamp and tungsten lamp design, change the lamp without optical debugging.

6,24-bit high speed, high precision A / D conversion, high instrument accuracy, fast reaction speed.

7, wide sample room, can accommodate 5-100mm of various specifications of the cuvette.

8. It can directly connect to the printer to print maps and experimental data.

9, the instrument adopts the suspension frame optical system design and the long light range optical path design, so as to greatly improve the stability and reliability of the instrument and the optical resolution of the instrument.

Spectrometers:

Optical System Double beam

Wavelength Range 190~1100nm

Band Width 1.8nm

Wavelength Accuracy ±0.3nm

Wavelength Repeatability ≤0.1nm

Photometric Accuracy ±0.3% τ(0-100%τ) ±0.002A(0~0.5A) ±0.003A(0.5A~1A)

Photometric Repeatability ±0.15% τ(0-100%τ) ±0.001A(0~0.5A) ±0.0015A(0.5A~1A)

Stray Light ≤0.03% τ (220nm NaI,340nm NaNO2)

Stability 0.0005A/h@500nm

Noise ± 0.0002A @500nm

Baseline Flatness ± 0.001A

Photometric Mode T,A,C,E

Wavelength Setting Automatic

Photometric Display Range -4~4A

Display Mode 6 inches high brightness blue LCD

Detector Import Silicon Photodiode

Light Source Import Deuterium Lamp & Tungsten Halogen Lamp

Power Requirement AC 220V/50Hz 110V/60Hz

Power 120W

Dimensions(W*D*H) 560×450×230mm

Weight 28Kg

Exhibition:

Competitive Advantage:

Our Company:

    Macylab Instruments Inc.is a high-tech enterprise with independent intellectual property rights . Macy hold the pioneering concept "technology - because you change " , and as a business purpose, and constantly explore, bold innovation. Especially in the field of analytical instruments ,Macy constantly develop advanced products that enable Macy to become a high-quality instrument resource supplier and leader。

    Macylab Instruments Inc.focus on UV/Vis spectrophotometer, including the 1100/1200 Series UV/Vis spectrophotometer, 1300 Series UV/Vis spectrophotometer, 1500 Series UV/Vis spectrophotometer, 1700 Series UV/Vis spectrophotometer meter, 1800 series double beam UV/Vis spectrophotometer and 1900 series double beam UV/Vis spectrophotometer.Our Atomic absorption spectrophotometer including :  AA-1800C flame atomic absorption spectrophotometer, AA-1800H Flame / Graphite Furnace Intergrated atomic absorption spectrophotometer. At present, our products have been widely used in organic chemistry, inorganic chemistry, biochemistry, medicine, environmental protection, metallurgy, petroleum, agriculture and other fields. At the same time, aesthetic analysis using the rich experience accumulated in product mechanical structure, optical design, electrical application and software development, combined with the latest actual market demand, will soon launch a number of new analysis instrument.

    Macylab's headquarter and production base is located in Shanghai, the marketing center in Beijing, and three R & D bases in Jiangsu, Shanghai, and Shandong. To take full advantage of the country's intellectual resources, MACY and the domestic and foreign research unit also conducted deep scientific research cooperation, will continue to put the research achievements into productivity .To better serve our customers, Macy has 12 domestic offices, tailored to meet the needs of your application solutions to improve the value of the products. At the same time continue to serve domestic users, Macy also with distribution in over 20 countries to establish a deep strategic partnership cooperation.

    Along with Macylab accelerate the pace and rank among the global brand instruments, Macylab increasing demands of our own, and we also hope to get the care and support of the community, Let us work and outlook together.Technology, will change because you and us.
